Pro Series 1400980376 Weld-On Jack Square Tube 12000lbs Sidewind Adj Travel

About this product

Square Jack - Drop Leg w/ Non-Spring Return - Sidewind - 26" Lift - 10,000 lbs

Sturdy steel construction provides heavy-duty durability
Weather-resistant inner and outer tubes have gray paint finish
Drop leg with non-spring return increases overall extension for maximum adjustability
Plunger pin positioned to the front
2 Grease zerk fittings allow for easy maintenance
Direct-weld design
Sidewind crank included
Integrated footplate
Specs:
Bracket height:
28-1/4" Retracted
54-1/4" Extended
Total lift: 26"
Travel: 12-1/2"
Drop leg: 13-1/2"
Lift capacity: 10,000 lbs
Static capacity: 12,000 lbs
